TPD2005F(EL,F)

Name: TPD2005F(EL,F)
Brand: TOSHIBA
SKU: 300281835-0000-0000-0000

TPD2005F(EL,F) - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

EL:エンボスリール左巻 F:RoHS品|汎用リニアIC | インテリジェントパワーデバイス

TPD2005F(EL,F) の詳細情報

型番	TPD2005F(EL,F)
メーカー	TOSHIBA
種別	汎用リニアIC
Built-in Protections	TRANSIENT; OVER CURRENT; THERMAL
Driver Number of Bits	8
Input Characteristics	STANDARD
Interface IC Type	BUFFER OR INVERTER BASED PERIPHERAL DRIVER
JESD-30 Code	R-PDSO-G24
Length	13 mm
Number of Functions	8
Number of Terminals	24
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current Flow Direction	SINK
Output Current-Max	0.005 A
Output Peak Current Limit-Nom	1 A
Output Polarity	TRUE
Package Body Material	PLASTIC/EPOXY
Package Code	SSOP
Package Equivalence Code	SOP24,.3,40
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, SHRINK PITCH Meter
Seated Height-Max	1.9 mm
Supply Current-Max	5 mA
Supply Voltage-Max	40 V
Supply Voltage-Min	8 V
Supply Voltage-Nom	12 V
Surface Mount	YES
Technology	MOS
Temperature Grade	INDUSTRIAL
Terminal Form	GULL WING
Terminal Pitch	1 mm
Terminal Position	DUAL
Turn-off Time	50 us
Turn-on Time	200 us
Width	6 mm
