TMPZ84C30AM-8 データシート

Name: TMPZ84C30AM-8
Brand: TOSHIBA
SKU: 300000755-0000-0000-0000

TMPZ84C30AM-8 - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TMPZ84C30AM-8 の詳細情報

型番	TMPZ84C30AM-8
メーカー	TOSHIBA
データシート
Additional Feature	DAISY CHAIN INTERRUPT STRUCTURE; PRESCALED /16, /256 TIMER I/P'S; SELECTABLE TIMER, COUNTER MODES
Bus Compatibility	Z80
Clock Frequency-Max	8 MHz
External Data Bus Width	8
Information Access Method	PARALLEL, DIRECT ADDRESS
JESD-30 Code	R-PDSO-G28
Length	18.5 mm
Number of Bits	8
Number of Terminals	28
Number of Timers	4
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-10 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Qualification Status	Not Qualified
Seated Height-Max	2.7 mm
Supply Current-Max	10 mA
Supply Voltage-Max	5.25 V
Supply Voltage-Min	4.75 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Width	8.8 mm
uPs/uCs/Peripheral ICs Type	TIMER, PROGRAMMABLE
