TMPZ84C30AM-6 データシート

Name: TMPZ84C30AM-6
Brand: TOSHIBA
SKU: 300000467-0000-0000-0000

TMPZ84C30AM-6 - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TMPZ84C30AM-6 の詳細情報

型番	TMPZ84C30AM-6
メーカー	TOSHIBA
データシート
Additional Feature	DAISY CHAIN INTERRUPT STRUCTURE; PRESCALED /16, /256 TIMER I/P'S; SELECTABLE TIMER, COUNTER MODES
Bus Compatibility	Z80
Clock Frequency-Max	6 MHz
External Data Bus Width	8
Information Access Method	PARALLEL, DIRECT ADDRESS
JESD-30 Code	R-PDSO-G28
JESD-609 Code	e0
Length	18.5 mm
Number of Bits	8
Number of Terminals	28
Number of Timers	4
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Qualification Status	Not Qualified
Seated Height-Max	2.7 mm
Supply Current-Max	7 mA
Supply Voltage-Max	5.5 V
Supply Voltage-Min	4.5 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	8.8 mm
uPs/uCs/Peripheral ICs Type	TIMER, PROGRAMMABLE
