TMPZ84C015BF-6 データシート

Name: TMPZ84C015BF-6
Brand: TOSHIBA
SKU: 300005825-0000-0000-0000

TMPZ84C015BF-6 - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TMPZ84C015BF-6 の詳細情報

型番	TMPZ84C015BF-6
メーカー	TOSHIBA
データシート
ADC Channels	NO
Additional Feature	BUILT-IN DYNAMIC RAM REFRESH CONTROLLER
Address Bus Width	16
Bit Size	8
Boundary Scan	NO
Clock Frequency-Max	6 MHz
DAC Channels	NO
DMA Channels	NO
External Data Bus Width	8
Format	FIXED POINT
Integrated Cache	NO
JESD-30 Code	R-PQFP-G100
Length	20 mm
Low Power Mode	YES
Number of DMA Channels	0
Number of External Interrupts	2
Number of I/O Lines	16
Number of Serial I/Os	2
Number of Terminals	100
Number of Timers	4
On Chip Data RAM Width	0
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
PWM Channels	NO
Package Body Material	PLASTIC/EPOXY
Package Code	QFP
Package Shape	RECTANGULAR
Package Style	FLATPACK Meter
Qualification Status	Not Qualified
RAM (words)	0
Seated Height-Max	3.05 mm
Supply Current-Max	35 mA
Supply Voltage-Max	5.5 V
Supply Voltage-Min	4.5 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	QUAD
Width	14 mm
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
