TMP95C063F データシート

Name: TMP95C063F
Brand: TOSHIBA
SKU: 300383720-0000-0000-0000

TMP95C063F - TOSHIBA の商品詳細ページです。

No Image

２営業日以内に回答いたします

TMP95C063F の詳細情報

型番	TMP95C063F
メーカー	TOSHIBA
種別	マイクロコンピュータ
データシート
ADC Channels	YES
Address Bus Width	24
Bit Size	16
CPU Family	TLCS-900/H
Clock Frequency-Max	25 MHz
DAC Channels	YES
DMA Channels	YES
External Data Bus Width	16
JESD-30 Code	S-PQFP-G144
Length	20 mm
Number of I/O Lines	91
Number of Terminals	144
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-20 Cel
PWM Channels	NO
Package Body Material	PLASTIC/EPOXY
Package Code	FQFP
Package Equivalence Code	QFP144,.87SQ,20
Package Shape	SQUARE
Package Style	FLATPACK Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	5 V
Qualification Status	Not Qualified
ROM Programmability	MROM
Seated Height-Max	4.45 mm
Speed	25 rpm
Sub Category	Microcontrollers
Supply Current-Max	50 mA
Supply Voltage-Max	5.5 V
Supply Voltage-Min	4.5 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	20 mm
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
