TMP82C54M-2 データシート

Name: TMP82C54M-2
Brand: TOSHIBA
SKU: 300028460-0000-0000-0000

TMP82C54M-2 - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TMP82C54M-2 の詳細情報

型番	TMP82C54M-2
メーカー	TOSHIBA
種別	マイクロコンピュータ
データシート
Additional Feature	6 PROGRAMMABLE MODES
External Data Bus Width	8
Information Access Method	PARALLEL, DIRECT ADDRESS
JESD-30 Code	R-PDSO-G24
JESD-609 Code	e0
Length	16 mm
Number of Bits	16
Number of Terminals	24
Number of Timers	3
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Qualification Status	Not Qualified
Seated Height-Max	2.8 mm
Supply Current-Max	30 mA
Supply Voltage-Max	5.5 V
Supply Voltage-Min	4.5 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	8.8 mm
uPs/uCs/Peripheral ICs Type	TIMER, PROGRAMMABLE
