TMP8155P データシート

Name: TMP8155P
Brand: TOSHIBA
SKU: 300028444-0000-0000-0000

TMP8155P - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TMP8155P の詳細情報

型番	TMP8155P
メーカー	TOSHIBA
種別	マイクロコンピュータ
データシート
CPU Family	8085
JESD-30 Code	R-PDIP-T40
JESD-609 Code	e0
Length	50.7 mm
Memory Organization	256X8
Number of Bits	14
Number of I/O Lines	22
Number of Ports	3
Number of Terminals	40
Number of Timers	1
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP40,.6
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	5 V
Qualification Status	Not Qualified
Seated Height-Max	4.8 mm
Sub Category	Parallel IO Port
Supply Current-Max	180 mA
Supply Voltage-Max	5.25 V
Supply Voltage-Min	4.75 V
Supply Voltage-Nom	5 V
Surface Mount	NO
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	15.24 mm
uPs/uCs/Peripheral ICs Type	PARALLEL IO PORT, GENERAL PURPOSE
