TMP47P403VNG データシート

Name: TMP47P403VNG
Brand: TOSHIBA
SKU: 300361460-0000-0000-0000

TMP47P403VNG - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TMP47P403VNG の詳細情報

型番	TMP47P403VNG
メーカー	TOSHIBA
データシート
ADC Channels	NO
Additional Feature	OPERATES AT 2.7 V MINIMUM SUPPLY @ 4.2 MHZ
Address Bus Width	0
Bit Size	4
Clock Frequency-Max	6 MHz
DAC Channels	NO
DMA Channels	NO
External Data Bus Width	0
JESD-30 Code	R-PDIP-T28
Length	25.6 mm
Number of I/O Lines	22
Number of Terminals	28
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-30 Cel
PWM Channels	NO
Package Body Material	PLASTIC/EPOXY
Package Code	SDIP
Package Shape	RECTANGULAR
Package Style	IN-LINE, SHRINK PITCH Meter
Qualification Status	Not Qualified
ROM Programmability	OTPROM
Seated Height-Max	4.1 mm
Speed	6 rpm
Supply Voltage-Max	5.5 V
Supply Voltage-Min	4.5 V
Supply Voltage-Nom	5 V
Surface Mount	NO
Technology	CMOS
Temperature Grade	OTHER
Terminal Form	THROUGH-HOLE
Terminal Pitch	1.778 mm
Terminal Position	DUAL
Width	15.24 mm
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
