TD62703PG データシート

Name: TD62703PG
Brand: TOSHIBA
SKU: 300221458-0000-0000-0000

TD62703PG - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

汎用リニアIC | 高耐圧ソース型ドライバ|パッケージ : DIP16

TD62703PG の詳細情報

型番	TD62703PG
メーカー	TOSHIBA
種別	汎用リニアIC
データシート
Data Input Mode	PARALLEL
Interface IC Type	VACUUM FLUORESCENT DISPLAY DRIVER
JESD-30 Code	R-PDIP-T14
Length	19.25 mm
Multiplexed Display Capability	NO
Negative Supply Voltage-Nom	-55 V
Number of Functions	1
Number of Segments	6
Number of Terminals	14
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP14,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	-55 V
Qualification Status	Not Qualified
Seated Height-Max	4.45 mm
Sub Category	Display Drivers
Surface Mount	NO
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	7.62 mm
