TD62309F データシート

Name: TD62309F
Brand: TOSHIBA
SKU: 300021121-0000-0000-0000

TD62309F - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TD62309F の詳細情報

型番	TD62309F
メーカー	TOSHIBA
種別	汎用リニアIC
データシート
Built-in Protections	TRANSIENT
Driver Number of Bits	6
Input Characteristics	STANDARD
Interface IC Type	BUFFER OR INVERTER BASED PERIPHERAL DRIVER
JESD-30 Code	R-PDSO-G16
JESD-609 Code	e0
Length	13 mm
Number of Functions	1
Number of Terminals	16
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Characteristics	OPEN-COLLECTOR
Output Current Flow Direction	SINK
Output Current-Max	0.45 A
Output Peak Current Limit-Nom	0.2 A
Output Polarity	INVERTED
Package Body Material	PLASTIC/EPOXY
Package Code	HSSOP
Package Equivalence Code	SOP16/24,.37,40
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, HEAT SINK/SLUG, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	5 V
Qualification Status	Not Qualified
Seated Height-Max	2.85 mm
Sub Category	Peripheral Drivers
Supply Current-Max	300 mA
Supply Voltage-Max	7 V
Supply Voltage-Min	3 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	GULL WING
Terminal Pitch	1 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	6.4 mm
