TCV7113F(TE12L,Q) データシート

Name: TCV7113F(TE12L,Q)
Brand: TOSHIBA
SKU: 300395376-0000-0000-0000

TCV7113F(TE12L,Q) - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TE12L:12mm幅テーピング Q:端子のみ鉛,ハロゲンフリー品

TCV7113F(TE12L,Q) の詳細情報

型番	TCV7113F(TE12L,Q)
メーカー	TOSHIBA
データシート
Additional Feature	ADJUSTABLE OUTPUT VOLTAGE FROM 0.8V
Analog IC - Other Type	SWITCHING REGULATOR
Control Mode	VOLTAGE-MODE
Input Voltage-Max	5.6 V
Input Voltage-Min	2.7 V
Input Voltage-Nom	3.3 V
JESD-30 Code	S-PDSO-F8
Length	5 mm
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	HSOF
Package Equivalence Code	FL8,.2
Package Shape	SQUARE
Package Style	SMALL OUTLINE, HEAT SINK/SLUG Meter
Qualification Status	Not Qualified
Seated Height-Max	1 mm
Sub Category	Switching Regulator or Controllers
Surface Mount	YES
Switcher Configuration	BUCK
Switching Frequency-Max	1200 kHz
Technology	CMOS
Temperature Grade	AUTOMOTIVE
Terminal Form	FLAT
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Width	5 mm
