TCR2EE18 データシート

Name: TCR2EE18
Brand: TOSHIBA
SKU: 300377785-0000-0000-0000

TCR2EE18 - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

汎用リニアIC | CMOSポイントレギュレータ

TCR2EE18 の詳細情報

型番	TCR2EE18
メーカー	TOSHIBA
カテゴリ	レギュレータ
種別	汎用リニアIC
データシート
Adjustability	FIXED
Dropout Voltage1-Max	0.31 V
Dropout Voltage1-Nom	0.23 V
IOUT (Max) (mA)	200
Input Voltage Absolute-Max	6 V
Input Voltage-Max	5.5 V
Input Voltage-Min	1.5 V
JESD-30 Code	R-PDFP-F6
Length	1.6 mm
Line Regulation-Max	0.015 %
Number of Functions	1
Number of Outputs	1
Number of Terminals	5
Operating Temperature, TJ-Max	150 Cel
Output Current1-Max	0.15 A
Output Voltage1-Max	1.818 V
Output Voltage1-Min	1.782 V
Output Voltage1-Nom	1.8 V
Package Body Material	PLASTIC/EPOXY
Package Code	DFP
Package Equivalence Code	FL6,.047,20
Package Shape	RECTANGULAR
Package Style	FLATPACK Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Qualification Status	Not Qualified
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Seated Height-Max	0.6 mm
Sub Category	Other Regulators
Surface Mount	YES
Technology	CMOS
Terminal Form	FLAT
Terminal Pitch	0.5 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
VIN (Max) (V)	6
VOUT (Typ.) (V)	1.8
Voltage Tolerance-Max	1 %
Width	1.2 mm
ピン数	5
