TC7S00FU データシート

Name: TC7S00FU
Brand: TOSHIBA
SKU: 300000554-0000-0000-0000

TC7S00FU - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TC7S00FU の詳細情報

型番	TC7S00FU
メーカー	TOSHIBA
カテゴリ	その他-汎用IC
データシート
Additional Feature	SEATED HT-CALCULATED
Family	HC/UH
IBIS
IO (Min)(mA)	2.6
JESD-30 Code	R-PDSO-G5
JESD-609 Code	e0
Length	2 mm
Load Capacitance (CL)	50 pF
Logic IC Type	NAND GATE
Max I(ol)	0.002 Amp
Number of Functions	1
Number of Inputs	2
Number of Terminals	5
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP5/6,.08
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	260
Power Supplies	2/6 V
Prop. Delay@Nom-Sup	125 ns
Propagation Delay (tpd)	25 ns
Qualification Status	Not Qualified
Schmitt Trigger	NO
Seated Height-Max	1.1 mm
Sub Category	Gates
Supply Voltage-Max (Vsup)	6 V
Supply Voltage-Min (Vsup)	2 V
Supply Voltage-Nom (Vsup)	4.5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	10
VCC (Max)(V)	6
VCC (Min)(V)	2
Width	1.25 mm
tpd_tpz (Typ.)(nsec)	9
グループ	TC7S
ゲート数	1
ピン数	5
機能1	Gate
機能2	NAND
