TC5565FL-15 データシート

Name: TC5565FL-15
Brand: TOSHIBA
SKU: 300017866-0000-0000-0000

TC5565FL-15 - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TC5565FL-15 の詳細情報

型番	TC5565FL-15
メーカー	TOSHIBA
データシート
Access Time-Max	150 ns
I/O Type	COMMON
JESD-30 Code	R-PDSO-G28
JESD-609 Code	e0
Memory Density	65536 bit
Memory IC Type	STANDARD SRAM
Memory Width	8
Number of Terminals	28
Number of Words	8192 words
Number of Words Code	8K
Operating Mode	ASYNCHRONOUS
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Organization	8KX8
Output Characteristics	3-STATE
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP28,.5
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	5 V
Qualification Status	Not Qualified
Standby Current-Max	1.5E-5 Amp
Sub Category	SRAMs
Supply Current-Max	0.045 mA
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
