TC55257DFTL-85V データシート

Name: TC55257DFTL-85V
Brand: TOSHIBA
SKU: 300017790-0000-0000-0000

TC55257DFTL-85V - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TC55257DFTL-85V の詳細情報

型番	TC55257DFTL-85V
メーカー	TOSHIBA
データシート
Access Time-Max	150 ns
Additional Feature	USER SELECTABLE 5V VCC
I/O Type	COMMON
JESD-30 Code	R-PDSO-G28
Length	11.8 mm
Memory Density	262144 bit
Memory IC Type	STANDARD SRAM
Memory Width	8
Number of Functions	1
Number of Ports	1
Number of Terminals	28
Number of Words	32768 words
Number of Words Code	32K
Operating Mode	ASYNCHRONOUS
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Organization	32KX8
Output Characteristics	3-STATE
Output Enable	YES
Package Body Material	PLASTIC/EPOXY
Package Code	TSOP1
Package Equivalence Code	TSSOP28,.53,22
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE Meter
Parallel/Serial	PARALLEL
Power Supplies	3/5 V
Qualification Status	Not Qualified
Seated Height-Max	1.2 mm
Standby Current-Max	1.0E-5 Amp
Standby Voltage-Min	2 V
Sub Category	SRAMs
Supply Current-Max	0.07 mA
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	2.7 V
Supply Voltage-Nom (Vsup)	3.3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Form	GULL WING
Terminal Pitch	0.55 mm
Terminal Position	DUAL
Width	8 mm
