TC51WHM516AXBN70 データシート

Name: TC51WHM516AXBN70
Brand: TOSHIBA
SKU: 300017550-0000-0000-0000

TC51WHM516AXBN70 - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TC51WHM516AXBN70 の詳細情報

型番	TC51WHM516AXBN70
メーカー	TOSHIBA
データシート
Access Time-Max	70 ns
I/O Type	COMMON
JESD-30 Code	R-PBGA-B48
Length	7 mm
Memory Density	33554432 bit
Memory IC Type	PSEUDO STATIC RAM
Memory Width	16
Number of Functions	1
Number of Terminals	48
Number of Words	2097152 words
Number of Words Code	2M
Operating Mode	ASYNCHRONOUS
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-25 Cel
Organization	2MX16
Output Characteristics	3-STATE
Package Body Material	PLASTIC/EPOXY
Package Code	TFBGA
Package Equivalence Code	BGA48,6X8,30
Package Shape	RECTANGULAR
Package Style	GRID ARRAY, THIN PROFILE, FINE PITCH Meter
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	3 V
Qualification Status	Not Qualified
Seated Height-Max	1.2 mm
Standby Current-Max	5.0E-6 Amp
Sub Category	Other Memory ICs
Supply Current-Max	0.04 mA
Supply Voltage-Max (Vsup)	3.3 V
Supply Voltage-Min (Vsup)	2.6 V
Supply Voltage-Nom (Vsup)	2.75 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	OTHER
Terminal Form	BALL
Terminal Pitch	0.75 mm
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	6 mm
