TC5118160AFT70 データシート

Name: TC5118160AFT70
Brand: TOSHIBA
SKU: 300007545-0000-0000-0000

TC5118160AFT70 - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TC5118160AFT70 の詳細情報

型番	TC5118160AFT70
メーカー	TOSHIBA
データシート
Access Mode	FAST PAGE
Access Time-Max	70 ns
Additional Feature	RAS ONLY/CAS BEFORE RAS/HIDDEN REFRESH
JESD-30 Code	R-PDSO-G44
JESD-609 Code	e0
Length	20.95 mm
Memory Density	16777216 bit
Memory IC Type	FAST PAGE DRAM
Memory Width	16
Number of Functions	1
Number of Ports	1
Number of Terminals	44
Number of Words	1048576 words
Number of Words Code	1M
Operating Mode	ASYNCHRONOUS
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Organization	1MX16
Output Characteristics	3-STATE
Package Body Material	PLASTIC/EPOXY
Package Code	TSOP2
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE Meter
Peak Reflow Temperature (Cel)	240
Qualification Status	Not Qualified
Refresh Cycles	1024
Seated Height-Max	1.2 mm
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	4.5 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	MOS
Temperature Grade	COMMERCIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	GULL WING
Terminal Pitch	0.8 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	10.16 mm
