TC4028BF データシート

Name: TC4028BF
Brand: TOSHIBA
SKU: 300017069-0000-0000-0000

TC4028BF - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

BCD-to-Decimal Decoder | 16ピン

TC4028BF の詳細情報

型番	TC4028BF
メーカー	TOSHIBA
種別	CMOSロジックIC
データシート
Additional Feature	NOT AVAILABLE IN JAPAN
Family	4000/14000/40000
Input Conditioning	STANDARD
JESD-30 Code	R-PDSO-G16
JESD-609 Code	e0
Length	9.9 mm
Load Capacitance (CL)	50 pF
Logic IC Type	DECIMAL DECODER/DRIVER
Max I(ol)	0.00061 Amp
Number of Functions	1
Number of Terminals	16
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Polarity	TRUE
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP16,.3
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	5/15 V
Prop. Delay@Nom-Sup	350 ns
Propagation Delay (tpd)	350 ns
Qualification Status	Not Qualified
Seated Height-Max	1.75 mm
Sub Category	Decoder/Drivers
Supply Voltage-Max (Vsup)	18 V
Supply Voltage-Min (Vsup)	3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	3.9 mm
