TB62801FG データシート

Name: TB62801FG
Brand: TOSHIBA
SKU: 300268997-0000-0000-0000

TB62801FG - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

汎用リニアIC | リニアCCD用クロックドライバ

TB62801FG の詳細情報

型番	TB62801FG
メーカー	TOSHIBA
種別	汎用リニアIC
データシート
Family	62801
Input Conditioning	STANDARD
JESD-30 Code	R-PDSO-G18
Length	13.25 mm
Logic IC Type	LOW SKEW CLOCK DRIVER
Number of Functions	1
Number of Inverted Outputs	2
Number of Terminals	18
Number of True Outputs	2
Operating Temperature-Max	60 Cel
Operating Temperature-Min	-25 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	HSSOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, HEAT SINK/SLUG, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Propagation Delay (tpd)	14 ns
Qualification Status	Not Qualified
Same Edge Skew-Max (tskwd)	2 ns
Seated Height-Max	2.85 mm
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	4.7 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	BICMOS
Temperature Grade	OTHER
Terminal Form	GULL WING
Terminal Pitch	1 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	6.4 mm
fmax-Min	20 MHz
