TB31213FNG データシート

Name: TB31213FNG
Brand: TOSHIBA
SKU: 300067685-0000-0000-0000

TB31213FNG - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TB31213FNG の詳細情報

型番	TB31213FNG
メーカー	TOSHIBA
データシート
Analog IC - Other Type	PLL FREQUENCY SYNTHESIZER
JESD-30 Code	R-PDSO-G24
Length	7.8 mm
Number of Functions	1
Number of Terminals	24
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-30 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	SSOP24,.3
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	2.2 V
Qualification Status	Not Qualified
Seated Height-Max	1.2 mm
Sub Category	PLL or Frequency Synthesis Circuits
Supply Current-Max (Isup)	22 mA
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	1.9 V
Supply Voltage-Nom (Vsup)	2.2 V
Surface Mount	YES
Technology	BICMOS
Temperature Grade	OTHER
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	5.6 mm
