TA78DS05F データシート

Name: TA78DS05F
Brand: TOSHIBA
SKU: 300015456-0000-0000-0000

TA78DS05F - TOSHIBA の商品詳細ページです。

No Image

２営業日以内に回答いたします

TA78DS05F の詳細情報

型番	TA78DS05F
メーカー	TOSHIBA
種別	3端子レギュレータ
データシート
Adjustability	FIXED
Dropout Voltage1-Max	0.3 V
Dropout Voltage1-Nom	0.2 V
Input Voltage Absolute-Max	29 V
Input Voltage-Max	26 V
Input Voltage-Min	5.35 V
JESD-30 Code	R-PSSO-F3
Length	4.5 mm
Line Regulation-Max	0.03 %
Load Regulation-Max	0.05 %
Number of Functions	1
Number of Outputs	1
Number of Terminals	3
Operating Temperature, TJ-Max	150 Cel
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current1-Max	0.01 A
Output Voltage1-Max	5.5 V
Output Voltage1-Min	4.5 V
Output Voltage1-Nom	5 V
Package Body Material	PLASTIC/EPOXY
Package Equivalence Code	TO-243
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Qualification Status	Not Qualified
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Seated Height-Max	1.6 mm
Sub Category	Other Regulators
Surface Mount	YES
Technology	BIPOLAR
Terminal Form	FLAT
Terminal Pitch	1.5 mm
Terminal Position	SINGLE
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Voltage Tolerance-Max	10 %
Width	2.5 mm
