TA76L431FT(TE85LF データシート

Name: TA76L431FT(TE85LF
Brand: TOSHIBA
SKU: 300281833-0000-0000-0000

TA76L431FT(TE85LF - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TA76L431FT(TE85LF の詳細情報

型番	TA76L431FT(TE85LF
メーカー	TOSHIBA
データシート
Additional Feature	OUTPUT VOLTAGE ADJUSTABLE FROM VREF TO 19V
Analog IC - Other Type	TWO TERMINAL VOLTAGE REFERENCE
JESD-30 Code	R-PDSO-F5
JESD-609 Code	e0
Length	2.1 mm
Number of Functions	1
Number of Outputs	1
Number of Terminals	5
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	0.04 A
Output Voltage-Max	2.515 V
Output Voltage-Min	2.465 V
Output Voltage-Nom	2.49 V
Package Body Material	PLASTIC/EPOXY
Package Code	VSOF
Package Equivalence Code	TSSOP6,.08
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, VERY THIN PROFILE Meter
Qualification Status	Not Qualified
Seated Height-Max	0.75 mm
Sub Category	Voltage References
Surface Mount	YES
Technology	BIPOLAR
Temp Coef of Voltage-Max	86.059 ppm/Cel
Temperature Grade	INDUSTRIAL
Terminal Finish	TIN LEAD
Terminal Form	FLAT
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Trim/Adjustable Output	YES V
Width	1.7 mm
