TA58L08F(TE16L1,NQ データシート

Name: TA58L08F(TE16L1,NQ
Brand: TOSHIBA
SKU: 300060196-0000-0000-0000

TA58L08F(TE16L1,NQ - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TA58L08F(TE16L1,NQ の詳細情報

型番	TA58L08F(TE16L1,NQ
メーカー	TOSHIBA
種別	レギュレータ
データシート
Adjustability	FIXED
Dropout Voltage1-Max	0.4 V
Dropout Voltage1-Nom	0.22 V
Input Voltage Absolute-Max	29 V
Input Voltage-Max	26 V
Input Voltage-Min	8.35 V
JESD-30 Code	R-PSSO-G2
Length	6.5 mm
Line Regulation-Max	0.015 %
Load Regulation-Max	0.04 %
Number of Functions	1
Number of Outputs	1
Number of Terminals	2
Operating Temperature, TJ-Max	150 Cel
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-40 Cel
Output Current1-Max	0.2 A
Output Voltage1-Max	8.32 V
Output Voltage1-Min	7.68 V
Output Voltage1-Nom	8 V
Package Body Material	PLASTIC/EPOXY
Package Equivalence Code	SMSIP3H,.38,90TB
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, HEAT SINK/SLUG Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Qualification Status	Not Qualified
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Seated Height-Max	2.7 mm
Sub Category	Other Regulators
Surface Mount	YES
Technology	BIPOLAR
Terminal Form	GULL WING
Terminal Pitch	2.3 mm
Terminal Position	SINGLE
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Voltage Tolerance-Max	4 %
Width	5.5 mm
