TA4800AF(T6L1Q) データシート

Name: TA4800AF(T6L1Q)
Brand: TOSHIBA
SKU: 300324549-0000-0000-0000

TA4800AF(T6L1Q) - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

TA4800AF(T6L1Q) の詳細情報

型番	TA4800AF(T6L1Q)
メーカー	TOSHIBA
データシート
Adjustability	ADJUSTABLE
Dropout Voltage1-Max	0.5 V
Dropout Voltage1-Nom	0.69 V
Input Voltage-Max	16 V
Input Voltage-Min	2.5 V
JESD-30 Code	R-PSSO-G5
Length	6.5 mm
Line Regulation-Max (%/V)	0.27
Load Regulation-Max(%)	1.6 %
Number of Functions	1
Number of Outputs	1
Number of Terminals	5
Operating Temperature, TJ-Max	135 Cel
Operating Temperature, TJ-Min	-40 Cel
Output Current1-Max	1 A
Output Voltage1-Max	9 V
Output Voltage1-Min	1.5 V
Output Voltage1-Nom	3.3 V
Package Body Material	PLASTIC/EPOXY
Package Equivalence Code	SMSIP5H,.37,50TB
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Packing Method	TR
Qualification Status	Not Qualified
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Seated Height-Max	2.7 mm
Sub Category	Other Regulators
Surface Mount	YES
Technology	BIPOLAR
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	SINGLE
Width	5.5 mm
