2SK2493 データシート

Name: 2SK2493
Brand: TOSHIBA
SKU: 30115464-0000-0000-0000

2SK2493 - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

MOSFET,接合形FET

2SK2493 の詳細情報

型番	2SK2493
メーカー	TOSHIBA
種別	MOSFET,接合形FET
データシート
Case Connection	DRAIN
Configuration	SINGLE
DS Breakdown Voltage-Min	16 V
Drain Current-Max (Abs) (ID)	5 A
Drain Current-Max (ID)	5 A
Drain-source On Resistance-Max	0.12 ohm
FET Technology	METAL-OXIDE SEMICONDUCTOR
JESD-30 Code	R-PSIP-T3
JESD-609 Code	e0
Number of Elements	1
Number of Terminals	2
Operating Mode	ENHANCEMENT MODE
Operating Temperature-Max	150 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	240
Polarity/Channel Type	N-CHANNEL
Power Dissipation-Max (Abs)	20 W
Pulsed Drain Current-Max (IDM)	20 A
Qualification Status	Not Qualified
Sub Category	FET General Purpose Power
Surface Mount	NO
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	GULL WING
Terminal Position	SINGLE
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Transistor Application	SWITCHING
Transistor Element Material	SILICON
