2SC4250 データシート

Name: 2SC4250
Brand: TOSHIBA
SKU: 30114481-0000-0000-0000

2SC4250 - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

トランジスタ

2SC4250 の詳細情報

型番	2SC4250
メーカー	TOSHIBA
種別	トランジスタ
データシート
Collector Current-Max (IC)	0.05 A
Collector-base Capacitance-Max	0.6 pF
Collector-emitter Voltage-Max	20 V
Configuration	SINGLE
DC Current Gain-Min (hFE)	40
Highest Frequency Band	VERY HIGH FREQUENCY BAND
JESD-30 Code	R-PDSO-F3
JESD-609 Code	e0
Number of Elements	1
Number of Terminals	3
Operating Temperature-Max	125 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	240
Polarity/Channel Type	NPN
Power Dissipation-Max (Abs)	0.1 W
Power Gain-Min (Gp)	20 dB
Qualification Status	Not Qualified
Sub Category	Other Transistors
Surface Mount	YES
Terminal Finish	TIN LEAD
Terminal Form	FLAT
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Transistor Application	AMPLIFIER
Transistor Element Material	SILICON
Transition Frequency-Nom (fT)	1400 MHz
