1S247
1
-
- 個
２営業日以内に回答いたします
1S247 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | 1S247 |
|---|---|
| メーカー | TOSHIBA |
| Additional Feature | HIGH RELIABILITY |
| Case Connection | ISOLATED |
| Configuration | SINGLE |
| Diode Element Material | SILICON |
| Diode Type | RECTIFIER DIODE |
| Dynamic Impedance-Max | 65 ohm |
| Forward Voltage-Max (VF) | 1.2 V |
| JEDEC-95 Code | DO-35 |
| JESD-30 Code | O-LALF-W2 |
| JESD-609 Code | e0 |
| Non-rep Pk Forward Current-Max | 0.3 A |
| Number of Elements | 1 |
| Number of Phases | 1 |
| Number of Terminals | 2 |
| Operating Temperature-Max | 150 Cel |
| Output Current-Max | 0.11 A |
| Package Body Material | GLASS |
| Package Shape | ROUND |
| Package Style | LONG FORM Meter |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Power Dissipation-Max | 0.3 W |
| Qualification Status | Not Qualified |
| Reference Voltage-Nom | 50 V |
| Rep Pk Reverse Voltage-Max | 40 V |
| Reverse Current-Max | 0.5 uA |
| Reverse Recovery Time-Max | 0.004 us |
| Sub Category | Rectifier Diodes |
| Surface Mount | NO |
| Terminal Finish | TIN LEAD |
| Terminal Form | WIRE |
| Terminal Position | AXIAL |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Voltage Tol-Max | 10 % |
| Working Test Current | 6 mA |
| 会社名称 | 株式会社東芝 |
|---|---|
| 設立 | 1875年7月 |
| 資本金 | 4,399億円 |
| 所在地 | 東京都港区芝浦1-1-1 |
| URL | http://www.semicon.toshiba.co.jp/eng/ |
