10GWJ2CZ47C データシート

Name: 10GWJ2CZ47C
Brand: TOSHIBA
SKU: 20252991-0000-0000-0000

10GWJ2CZ47C - TOSHIBA の商品詳細ページです。

２営業日以内に回答いたします

10GWJ2CZ47C の詳細情報

型番	10GWJ2CZ47C
メーカー	TOSHIBA
データシート
Additional Feature	FREE WHEELING DIODE
Application	GENERAL PURPOSE
Case Connection	ISOLATED
Configuration	COMMON CATHODE, 2 ELEMENTS
Diode Element Material	SILICON
Diode Type	RECTIFIER DIODE
Forward Voltage-Max (VF)	0.55 V
JEDEC-95 Code	TO-220AB
JESD-30 Code	R-PSFM-T3
Non-rep Pk Forward Current-Max	110 A
Number of Elements	1
Number of Phases	1
Number of Terminals	3
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	10 A
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	FLANGE MOUNT Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Qualification Status	Not Qualified
Rep Pk Reverse Voltage-Max	40 V
Reverse Current-Max	3500 uA
Sub Category	Rectifier Diodes
Surface Mount	NO
Technology	SCHOTTKY
Terminal Form	THROUGH-HOLE
Terminal Position	SINGLE
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
