XTR111AIDGQR データシート

Name: XTR111AIDGQR
Brand: TI
SKU: 340016087-0000-0000-0000

XTR111AIDGQR - TI の商品詳細ページです。

２営業日以内に回答いたします

XTR111AIDGQR の詳細情報

型番	XTR111AIDGQR
メーカー	TI
データシート
Analog IC - Other Type	ANALOG CIRCUIT
JESD-30 Code	S-PDSO-G10
JESD-609 Code	e4
Length	3 mm
Moisture Sensitivity Level	2
Number of Channels	1
Number of Functions	1
Number of Terminals	10
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-55 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	HTSSOP
Package Equivalence Code	TSSOP10,.19,20
Package Shape	SQUARE
Package Style	SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	24 V
Qualification Status	Not Qualified
Seated Height-Max	1.1 mm
Sub Category	Other Analog ICs
Supply Current-Max (Isup)	0.55 mA
Supply Voltage-Max (Vsup)	44 V
Supply Voltage-Min (Vsup)	7 V
Supply Voltage-Nom (Vsup)	24 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	MILITARY
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	3 mm
