TXS0102DQMR データシート

Name: TXS0102DQMR
Brand: TI
SKU: 300322107-0000-0000-0000

TXS0102DQMR - TI の商品詳細ページです。

２営業日以内に回答いたします

TXS0102DQMR の詳細情報

型番	TXS0102DQMR
メーカー	TI
データシート
Interface IC Type	INTERFACE CIRCUIT
JESD-30 Code	R-PDSO-N8
JESD-609 Code	e4
Length	1.8 mm
Moisture Sensitivity Level	1
Number of Bits	2
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Characteristics	3-STATE
Package Body Material	PLASTIC/EPOXY
Package Code	VSON
Package Equivalence Code	SOLCC8,.05,16
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, VERY THIN PROFILE Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	1.8/3.3,2.5/5 V
Qualification Status	Not Qualified
Seated Height-Max	0.4 mm
Sub Category	Other Interface ICs
Supply Current-Max	0.01 mA
Supply Voltage-Max	3.6 V
Supply Voltage-Min	1.65 V
Supply Voltage-Nom	1.8 V
Supply Voltage1-Max	5.5 V
Supply Voltage1-Min	2.3 V
Supply Voltage1-Nom	2.5 V
Surface Mount	YES
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	NO LEAD
Terminal Pitch	0.4 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	1.2 mm
