TXB0102DCUR の詳細情報

型番	TXB0102DCUR
メーカー	TI
データシート
Interface IC Type	INTERFACE CIRCUIT
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e4
Length	2.3 mm
Moisture Sensitivity Level	1
Number of Bits	2
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Characteristics	3-STATE
Package Body Material	PLASTIC/EPOXY
Package Code	VSSOP
Package Equivalence Code	TSSOP8,.12,20
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	1.2/3.6,1.8/5 V
Qualification Status	Not Qualified
Seated Height-Max	0.9 mm
Sub Category	Other Interface ICs
Supply Current-Max	0.008 mA
Supply Voltage-Max	3.6 V
Supply Voltage-Min	1.2 V
Supply Voltage-Nom	1.5 V
Supply Voltage1-Max	5.5 V
Supply Voltage1-Min	1.65 V
Supply Voltage1-Nom	1.8 V
Surface Mount	YES
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	2 mm
