TPS82084SILT

Name: TPS82084SILT
Brand: TI
SKU: 300392741-0000-0000-0000

TPS82084SILT - TI の商品詳細ページです。

２営業日以内に回答いたします

TPS82084SILT の詳細情報

型番	TPS82084SILT
メーカー	TI
Additional Feature	ADJUSTABLE OUTPUT MODE FROM 0.8 TO 6V
Analog IC - Other Type	SWITCHING REGULATOR
Control Technique	PULSE WIDTH MODULATION
Input Voltage-Max	6 V
Input Voltage-Min	2.5 V
Input Voltage-Nom	3.6 V
JESD-30 Code	R-XDMA-N8
Length	3 mm
Moisture Sensitivity Level	2
Number of Functions	1
Number of Outputs	1
Number of Terminals	8
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	2 A
Output Voltage-Max	6 V
Output Voltage-Min	0.8 V
Package Body Material	UNSPECIFIED
Package Shape	RECTANGULAR
Package Style	MICROELECTRONIC ASSEMBLY Meter
Peak Reflow Temperature (Cel)	260
Seated Height-Max	1.33 mm
Surface Mount	YES
Switcher Configuration	BUCK
Switching Frequency-Max	2600 kHz
Temperature Grade	AUTOMOTIVE
Terminal Form	NO LEAD
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	2.8 mm
