TPS62050DGSR データシート

Name: TPS62050DGSR
Brand: TI
SKU: 300031477-0000-0000-0000

TPS62050DGSR - TI の商品詳細ページです。

２営業日以内に回答いたします

TPS62050DGSR の詳細情報

型番	TPS62050DGSR
メーカー	TI
データシート
Additional Feature	OPERATES IN ADJUSTABLE MODE FROM 0.7 TO 6V, ALSO HAS CONTROL TECHNIQUE OF PFM
Analog IC - Other Type	SWITCHING REGULATOR
Control Mode	VOLTAGE-MODE
Control Technique	PULSE WIDTH MODULATION
Input Voltage-Max	10 V
Input Voltage-Min	2.7 V
Input Voltage-Nom	7.2 V
JESD-30 Code	S-PDSO-G10
JESD-609 Code	e4
Length	3 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	10
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	0.8 A
Output Voltage-Max	6 V
Output Voltage-Min	0.7 V
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Shape	SQUARE
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	1.1 mm
Surface Mount	YES
Switcher Configuration	BUCK
Switching Frequency-Max	1200 kHz
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag)
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	3 mm
