TPS60403DBVT データシート

Name: TPS60403DBVT
Brand: TI
SKU: 300133111-0000-0000-0000

TPS60403DBVT - TI の商品詳細ページです。

２営業日以内に回答いたします

TPS60403DBVT の詳細情報

型番	TPS60403DBVT
メーカー	TI
データシート
Analog IC - Other Type	SWITCHED CAPACITOR CONVERTER
Input Voltage-Max	5.5 V
Input Voltage-Min	1.6 V
Input Voltage-Nom	5 V
JESD-30 Code	R-PDSO-G5
JESD-609 Code	e4
Length	2.9 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	5
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	0.06 A
Output Voltage-Max	-1.6 V
Output Voltage-Min	-5.25 V
Package Body Material	PLASTIC/EPOXY
Package Code	LSSOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	1.45 mm
Surface Mount	YES
Switcher Configuration	DOUBLER INVERTER
Switching Frequency-Max	400 kHz
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	0.95 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	1.6 mm
