TPS563201DDCR

Name: TPS563201DDCR
Brand: TI
SKU: 300395763-0000-0000-0000

TPS563201DDCR - TI の商品詳細ページです。

２営業日以内に回答いたします

TPS563201DDCR の詳細情報

型番	TPS563201DDCR
メーカー	TI
Additional Feature	ALSO OPERATES IN ADJUSTABLE MODE FROM 0.76 TO 7V
Analog IC - Other Type	SWITCHING REGULATOR
Control Technique	PULSE WIDTH MODULATION
Input Voltage-Max	17 V
Input Voltage-Min	4.5 V
Input Voltage-Nom	12 V
JESD-30 Code	R-PDSO-G6
JESD-609 Code	e3
Length	2.9 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	6
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	3 A
Output Voltage-Max	7 V
Output Voltage-Min	0.76 V
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Seated Height-Max	1.1 mm
Surface Mount	YES
Switcher Configuration	BUCK
Switching Frequency-Max	580 kHz
Temperature Grade	AUTOMOTIVE
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	0.95 mm
Terminal Position	DUAL
Width	1.6 mm
