TPS54531DDAR データシート

Name: TPS54531DDAR
Brand: TI
SKU: 300391831-0000-0000-0000

TPS54531DDAR - TI の商品詳細ページです。

２営業日以内に回答いたします

TPS54531DDAR の詳細情報

型番	TPS54531DDAR
メーカー	TI
データシート
Additional Feature	ADJUSTABLE OUTPUT VOLTAGE DOWN TO 0.8 V
Analog IC - Other Type	SWITCHING REGULATOR
Control Mode	CURRENT-MODE
Control Technique	PULSE WIDTH MODULATION
Input Voltage-Max	28 V
Input Voltage-Min	3.5 V
Input Voltage-Nom	12 V
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e4
Length	4.9 mm
Moisture Sensitivity Level	2
Number of Functions	1
Number of Outputs	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	5 A
Output Voltage-Max	25 V
Output Voltage-Min	0.8 V
Package Body Material	PLASTIC/EPOXY
Package Code	HLSOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, HEAT SINK/SLUG, LOW PROFILE Meter
Peak Reflow Temperature (Cel)	260
Seated Height-Max	1.7 mm
Surface Mount	YES
Switcher Configuration	BUCK
Switching Frequency-Max	570 kHz
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	3.9 mm
