TPS2553DRVR データシート

Name: TPS2553DRVR
Brand: TI
SKU: 300299046-0000-0000-0000

TPS2553DRVR - TI の商品詳細ページです。

２営業日以内に回答いたします

TPS2553DRVR の詳細情報

型番	TPS2553DRVR
メーカー	TI
データシート
Adjustable Threshold	YES
Analog IC - Other Type	POWER SUPPLY SUPPORT CIRCUIT
JESD-30 Code	S-PDSO-N6
JESD-609 Code	e4
Length	2 mm
Moisture Sensitivity Level	1
Number of Channels	1
Number of Functions	1
Number of Terminals	6
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	HVSON
Package Shape	SQUARE
Package Style	SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	0.8 mm
Supply Current-Max (Isup)	0.14 mA
Supply Voltage-Max (Vsup)	6.5 V
Supply Voltage-Min (Vsup)	2.5 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	NO LEAD
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	2 mm
