TPS2121RUXR
1
-
- 個
２営業日以内に回答いたします
TPS2121RUXR の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | TPS2121RUXR |
|---|---|
| メーカー | TI |
| Adjustable Threshold | YES |
| Analog IC - Other Type | POWER SUPPLY SUPPORT CIRCUIT |
| JESD-30 Code | R-PQCC-N12 |
| JESD-609 Code | e4 |
| Length | 2.5 mm |
| Moisture Sensitivity Level | 1 |
| Number of Channels | 1 |
| Number of Functions | 1 |
| Number of Terminals | 12 |
| Operating Temperature-Max | 125 Cel |
| Operating Temperature-Min | -40 Cel |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | HQCCN |
| Package Shape | RECTANGULAR |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG Meter |
| Peak Reflow Temperature (Cel) | 260 |
| Seated Height-Max | 1 mm |
| Supply Voltage-Max (Vsup) | 22 V |
| Supply Voltage-Min (Vsup) | 2.8 V |
| Supply Voltage-Nom (Vsup) | 12 V |
| Surface Mount | YES |
| Temperature Grade | AUTOMOTIVE |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) |
| Terminal Form | NO LEAD |
| Terminal Pitch | 0.5 mm |
| Terminal Position | QUAD |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Width | 2 mm |
| 会社名称 | Texas Instruments Incorporated. |
|---|---|
| 設立 | 1930 |
| 資本金 | USD 816 million |
| 所在地 | 12500 TI Boulevard Dallas, Texas 75243 USA |
| URL | http://www.ti.com/ |
