TPIC84125TPWPRQ1 データシート

Name: TPIC84125TPWPRQ1
Brand: TI
SKU: 300300745-0000-0000-0000

TPIC84125TPWPRQ1 - TI の商品詳細ページです。

２営業日以内に回答いたします

TPIC84125TPWPRQ1 の詳細情報

型番	TPIC84125TPWPRQ1
メーカー	TI
データシート
High Side Driver	YES
Input Characteristics	STANDARD
Interface IC Type	HALF BRIDGE BASED MOSFET DRIVER
JESD-30 Code	R-PDSO-G28
JESD-609 Code	e4
Length	9.7 mm
Moisture Sensitivity Level	3
Number of Functions	1
Number of Terminals	28
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-40 Cel
Output Peak Current Limit-Nom	0.8 A
Package Body Material	PLASTIC/EPOXY
Package Code	HTSSOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Screening Level	AEC-Q100
Seated Height-Max	1.2 mm
Supply Current-Max	1300 mA
Supply Voltage-Max	38 V
Supply Voltage-Min	7 V
Supply Voltage-Nom	16 V
Surface Mount	YES
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	4.4 mm
