TPD4E001DCKR データシート

Name: TPD4E001DCKR
Brand: TI
SKU: 300328328-0000-0000-0000

TPD4E001DCKR - TI の商品詳細ページです。

２営業日以内に回答いたします

TPD4E001DCKR の詳細情報

型番	TPD4E001DCKR
メーカー	TI
データシート
Breakdown Voltage-Min	11 V
Clamping Voltage-Max	25 V
Configuration	SINGLE
Diode Element Material	SILICON
Diode Type	TRANS VOLTAGE SUPPRESSOR DIODE
JEDEC-95 Code	MO-203AB
JESD-30 Code	R-PDSO-G6
JESD-609 Code	e4
Moisture Sensitivity Level	1
Non-rep Peak Rev Power Dis-Max	100 W
Number of Elements	1
Number of Terminals	6
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Polarity	UNIDIRECTIONAL
Reference Standard	IEC-61000-4-2, 4-5
Rep Pk Reverse Voltage-Max	5.5 V
Reverse Current-Max	0.001 uA
Sub Category	Transient Suppressors
Surface Mount	YES
Technology	AVALANCHE
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
