TPA6110A2DGNR データシート

Name: TPA6110A2DGNR
Brand: TI
SKU: 300030745-0000-0000-0000

TPA6110A2DGNR - TI の商品詳細ページです。

２営業日以内に回答いたします

TPA6110A2DGNR の詳細情報

型番	TPA6110A2DGNR
メーカー	TI
データシート
Bandwidth-Nom	20 kHz
Consumer IC Type	AUDIO AMPLIFIER
Gain	20 dB
Harmonic Distortion	0.1 %
JESD-30 Code	S-PDSO-G8
JESD-609 Code	e4
Length	3 mm
Moisture Sensitivity Level	1
Number of Channels	2
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Power-Nom	0.15 W
Package Body Material	PLASTIC/EPOXY
Package Code	HTSSOP
Package Equivalence Code	TSSOP8,.19
Package Shape	SQUARE
Package Style	SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	3.3/5 V
Qualification Status	Not Qualified
Seated Height-Max	1.1 mm
Sub Category	Audio/Video Amplifiers
Supply Current-Max	3 mA
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	2.5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	3 mm
