TPA2011D1YFFR データシート

Name: TPA2011D1YFFR
Brand: TI
SKU: 300292957-0000-0000-0000

TPA2011D1YFFR - TI の商品詳細ページです。

２営業日以内に回答いたします

TPA2011D1YFFR の詳細情報

型番	TPA2011D1YFFR
メーカー	TI
データシート
Bandwidth-Nom	20 kHz
Consumer IC Type	CLASS D AUDIO AMPLIFIER
JESD-30 Code	S-XBGA-B9
JESD-609 Code	e1
Length	1.6 mm
Moisture Sensitivity Level	1
Noise Figure-Nom	95 dB
Number of Channels	1
Number of Functions	1
Number of Terminals	9
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Power-Nom	3.2 W
Package Body Material	UNSPECIFIED
Package Code	VFBGA
Package Equivalence Code	BGA9,3X3,16
Package Shape	SQUARE
Package Style	GRID ARRAY, VERY THIN PROFILE, FINE PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	3/5 V
Qualification Status	Not Qualified
Seated Height-Max	0.625 mm
Sub Category	Audio/Video Amplifiers
Supply Current-Max	2.5 mA
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	2.5 V
Surface Mount	YES
Temperature Grade	INDUSTRIAL
Terminal Finish	Tin/Silver/Copper (Sn/Ag/Cu)
Terminal Form	BALL
Terminal Pitch	0.4 mm
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	1.6 mm
