TPA2005D1ZQYR データシート

Name: TPA2005D1ZQYR
Brand: TI
SKU: 300030682-0000-0000-0000

TPA2005D1ZQYR - TI の商品詳細ページです。

２営業日以内に回答いたします

TPA2005D1ZQYR の詳細情報

型番	TPA2005D1ZQYR
メーカー	TI
データシート
Bandwidth-Nom	20 kHz
Consumer IC Type	AUDIO AMPLIFIER
Harmonic Distortion	10 %
JESD-30 Code	S-PBGA-B
JESD-609 Code	e1
Length	2.5 mm
Moisture Sensitivity Level	2
Noise Figure-Nom	97 dB
Number of Channels	1
Number of Functions	1
Number of Terminals	15
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Power-Nom	1.45 W
Package Body Material	PLASTIC/EPOXY
Package Code	BGA
Package Equivalence Code	BGA15,4X4,20
Package Shape	SQUARE
Package Style	GRID ARRAY Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	3/5 V
Qualification Status	Not Qualified
Screening Level	AEC-Q100
Seated Height-Max	1 mm
Sub Category	Audio/Video Amplifiers
Supply Current-Max	4.5 mA
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	2.5 V
Surface Mount	YES
Temperature Grade	INDUSTRIAL
Terminal Finish	Tin/Silver/Copper (Sn/Ag/Cu)
Terminal Form	BALL
Terminal Pitch	0.5 mm
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	2.5 mm
