TMS320DM6441ZWT

Name: TMS320DM6441ZWT
Brand: TI
SKU: 300117461-0000-0000-0000

TMS320DM6441ZWT - TI の商品詳細ページです。

２営業日以内に回答いたします

TMS320DM6441ZWT の詳細情報

型番	TMS320DM6441ZWT
メーカー	TI
Additional Feature	DSP, C64X-594 MHZ, 32-BIT, 4752 MIPS; ARM926EJ-S, 297 MHZ ,32-BIT; ALSO REQUIRES 3.3V I/O SUPPLY
Bit Size	32
Format	FIXED POINT
JESD-30 Code	S-PBGA-B361
Length	16 mm
Number of Terminals	361
Operating Temperature-Max	85 Cel
Operating Temperature-Min	0 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	LFBGA
Package Equivalence Code	BGA361,19X19,32
Package Shape	SQUARE
Package Style	GRID ARRAY, LOW PROFILE, FINE PITCH Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	1.2,1.8,3.3 V
Qualification Status	Not Qualified
RAM (words)	16384
Seated Height-Max	1.4 mm
Sub Category	Digital Signal Processors
Supply Voltage-Max	1.1 V
Supply Voltage-Min	1 V
Supply Voltage-Nom	1.05 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	OTHER
Terminal Form	BALL
Terminal Pitch	0.8 mm
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	16 mm
uPs/uCs/Peripheral ICs Type	MICROPROCESSOR CIRCUIT
