TMS320C542PGE2-40 の詳細情報

型番	TMS320C542PGE2-40
メーカー	TI
データシート
Address Bus Width	23
Barrel Shifter	YES
Bit Size	16
Boundary Scan	YES
Clock Frequency-Max	20 MHz
External Data Bus Width	16
Format	FIXED POINT
Integrated Cache	NO
Internal Bus Architecture	MULTIPLE
JESD-30 Code	S-PQFP-G144
JESD-609 Code	e4
Length	20 mm
Low Power Mode	YES
Moisture Sensitivity Level	1
Number of DMA Channels	0
Number of External Interrupts	5
Number of Serial I/Os	0
Number of Terminals	144
Number of Timers	1
On Chip Data RAM Width	16
On Chip Program ROM Width	16
Package Body Material	PLASTIC/EPOXY
Package Code	LFQFP
Package Equivalence Code	QFP144,.87SQ,20
Package Shape	SQUARE
Package Style	FLATPACK, LOW PROFILE, FINE PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	5 V
Qualification Status	Not Qualified
RAM (words)	5120
ROM Programmability	MROM
Seated Height-Max	1.6 mm
Sub Category	Digital Signal Processors
Supply Voltage-Max	5.25 V
Supply Voltage-Min	4.75 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	CMOS
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	20 mm
uPs/uCs/Peripheral ICs Type	DIGITAL SIGNAL PROCESSOR, OTHER
