TL431CP データシート

Name: TL431CP
Brand: TI
SKU: 300000506-0000-0000-0000

TL431CP - TI の商品詳細ページです。

２営業日以内に回答いたします

TL431CP の詳細情報

型番	TL431CP
メーカー	TI
データシート
Additional Feature	OUTPUT VOLTAGE ADJUSTABLE FROM 2.495V TO 36V
Analog IC - Other Type	THREE TERMINAL VOLTAGE REFERENCE
JESD-30 Code	R-PDIP-T8
JESD-609 Code	e0
Length	4.4 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	3
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-25 Cel
Output Current-Max	0.1 A
Output Voltage-Max	2.508 V
Output Voltage-Min	2.423 V
Output Voltage-Nom	2.495 V
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP8,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	1.2 mm
Sub Category	Voltage References
Supply Current-Max (Isup)	1 mA
Supply Voltage-Max (Vsup)	36 V
Supply Voltage-Min (Vsup)	2.495 V
Surface Mount	NO
Technology	BIPOLAR
Temp Coef of Voltage-Max	61.942 ppm/Cel
Temperature Grade	COMMERCIAL
Terminal Finish	MATTE TIN
Terminal Form	FLAT
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	40
Trim/Adjustable Output	NO V
Voltage Tolerance-Max	2 %
Width	2.45 mm
