TL044CN データシート

Name: TL044CN
Brand: TI
SKU: 300279364-0000-0000-0000

TL044CN - TI の商品詳細ページです。

２営業日以内に回答いたします

TL044CN の詳細情報

型番	TL044CN
メーカー	TI
データシート
Amplifier Type	OPERATIONAL AMPLIFIER
Architecture	VOLTAGE-FEEDBACK
Average Bias Current-Max (IIB)	0.25 uA
Common-mode Reject Ratio-Min	60 dB
Common-mode Reject Ratio-Nom	72 dB
Frequency Compensation	YES
Input Offset Voltage-Max	5000 uV
JESD-30 Code	R-PDIP-T16
Length	19.305 mm
Low-Bias	NO
Low-Offset	NO
Micropower	YES
Neg Supply Voltage Limit-Max	-18 V
Neg Supply Voltage-Nom (Vsup)	-15 V
Number of Functions	4
Number of Terminals	16
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP16,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power	NO
Power Supplies	+-15 V
Programmable Power	NO
Qualification Status	Not Qualified
Seated Height-Max	5.08 mm
Slew Rate-Nom	0.5 V/us
Sub Category	Operational Amplifier
Supply Current-Max	0.5 mA
Supply Voltage Limit-Max	18 V
Supply Voltage-Nom (Vsup)	15 V
Surface Mount	NO
Technology	BIPOLAR
Temperature Grade	COMMERCIAL
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Unity Gain BW-Nom	500 kHz
Voltage Gain-Min	1000
Wideband	NO
Width	7.62 mm
