THS7316D データシート

Name: THS7316D
Brand: TI
SKU: 300090672-0000-0000-0000

THS7316D - TI の商品詳細ページです。

２営業日以内に回答いたします

THS7316D の詳細情報

型番	THS7316D
メーカー	TI
データシート
Bandwidth-Nom	36000 kHz
Consumer IC Type	VIDEO AMPLIFIER
Gain	6 dB
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e4
Length	4.9 mm
Moisture Sensitivity Level	2
Number of Channels	3
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP8,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	3.3/5 V
Qualification Status	Not Qualified
Seated Height-Max	1.75 mm
Sub Category	Audio/Video Amplifiers
Supply Current-Max	26 mA
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	2.85 V
Surface Mount	YES
Technology	BICMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	3.9 mm
