TCA9517DGKR

Name: TCA9517DGKR
Brand: TI
SKU: 300366784-0000-0000-0000

TCA9517DGKR - TI の商品詳細ページです。

２営業日以内に回答いたします

TCA9517DGKR の詳細情報

型番	TCA9517DGKR
メーカー	TI
Additional Feature	ALSO HAVE 2.7 MIN INPUT
Interface IC Type	INTERFACE CIRCUIT
JESD-30 Code	S-PDSO-G8
JESD-609 Code	e4
Length	3 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Shape	SQUARE
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Screening Level	AEC-Q100
Seated Height-Max	1.1 mm
Supply Voltage-Max	5.25 V
Supply Voltage-Min	0.9 V
Supply Voltage-Nom	3.3 V
Supply Voltage1-Max	5.25 V
Supply Voltage1-Min	2.7 V
Supply Voltage1-Nom	3.3 V
Surface Mount	YES
Technology	BICMOS
Temperature Grade	AUTOMOTIVE
Terminal Finish	Nickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	3 mm
