TCA6424ARGJR の詳細情報

  • 仕様・詳細
  • メーカー情報
型番TCA6424ARGJR
メーカーTI
データシートProduct_list_pdf
Address Bus Width 2
Clock Frequency-Max 0.4 MHz
JESD-30 Code S-PQCC-N32
JESD-609 Code e4
Length 5 mm
Moisture Sensitivity Level 1
Number of Bits 24
Number of I/O Lines 24
Number of Ports 3
Number of Terminals 32
Operating Temperature-Max 85 Cel
Operating Temperature-Min -40 Cel
Package Body Material PLASTIC/EPOXY
Package Code HVQCCN
Package Equivalence Code LCC32,.2SQ,20
Package Shape SQUARE
Package Style CHIP CARRIER Meter
Peak Reflow Temperature (Cel) 260
Power Supplies 2/5 V
Qualification Status Not Qualified
Seated Height-Max 0.6 mm
Sub Category Parallel IO Port
Supply Current-Max 0.03 mA
Supply Voltage-Max 5.5 V
Supply Voltage-Min 1.65 V
Supply Voltage-Nom 3.3 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form NO LEAD
Terminal Pitch 0.5 mm
Terminal Position QUAD
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Width 5 mm
uPs/uCs/Peripheral ICs Type PARALLEL IO PORT, GENERAL PURPOSE
